mgschwan/viture_virtual_display: Virtual display with Viture Pro XR glasses using hdmi in on an OrangePi

Attention this is still in early development and not fully functional yet. It will work but performance needs to be improved a lot.

v4l2_gl captures video from a HDMI-in on an OrangePI 5 Plus using the hdmirx V4L2 device, converts frames to RGB, and displays them in real-time on a textured quad in an OpenGL window. It supports Viture headset IMU integration, test patterns, and plane geometry.

To run this as intended you need an OrangePi 5 Plus with armbian ( we are using BredOS ) that has Device Tree Overlays enabled and has the hdmi-rx device tree overlay active.

If you are using a Raspberry Pi or other device without HDMI-in you need a USB capture card that is supported on your Linux version

For testing purposes you can run it on a laptop with a webcam but that does not provide you with a virtual display.

This requires a linux based OS and installed gcc and build tools.

To compile and run this application, ensure the following libraries are installed:

• OpenGL and GLUT libraries:
  These are essential for creating the window and rendering graphics. On Debian/Ubuntu-based systems, you can install them using:

  sudo apt update
  sudo apt install freeglut3-dev


• libv4l2 library:

  sudo apt install libv4l-dev


• libhidapi-dev (optional): If your are using the revers engineered protocol instead of the official Viture SDK

  sudo apt install libhidapi-dev


Depending on the architecture you are running it on use the reverse engineered protocol version ( ARM ) or the official Viture SDK version ( X86 )

This will generate the executable v4l2_gl

This will generate the executable v4l2_gl_viture_sdk

Execute the compiled application from your terminal:

or

sudo ./v4l2_gl_viture_sdk [options]

Quickly shake your head left/right 3 times to reset the rotation to the center position after the IMU has drifted too far.

The application supports the following command-line options:

• --device :
  Specifies the V4L2 device path (e.g., /dev/video0).
  Default: /dev/video0.
  Example: ./v4l2_gl --device /dev/video1

• --fullscreen:
  Runs the application in fullscreen mode.
  Default: false (disabled).
  Example: ./v4l2_gl --fullscreen

• --viture:
  Enables integration with Viture headset IMU for controlling the rotation of the displayed plane. The Viture SDK and device must be correctly set up.
  Default: false (disabled).
  Example: ./v4l2_gl --viture

• --test-pattern:
  Displays a generated test pattern on the plane instead of the live camera feed. Useful for testing rendering and transformations.
  Default: false (disabled).
  Example: ./v4l2_gl --test-pattern

• --plane-distance :
  Sets the distance at which the plane orbits the world origin. is a floating-point value.
  Default: 1.0.
  Example: ./v4l2_gl --plane-distance 0.5

• --plane-scale :
  Sets a scale multiplier for the size of the plane. is a floating-point value (must be > 0).
  Default: 1.0 (original size). Values greater than 1.0 enlarge the plane, less than 1.0 shrink it. Values ./v4l2_gl –plane-scale 1.5

You can combine these options:

./v4l2_gl --device /dev/video1 --viture --fullscreen --plane-distance 0.8 --plane-scale 1.2 --test-pattern

This command would:

• Use V4L2 device /dev/video1.
• Enable Viture IMU.
• Run in fullscreen.
• Set the plane orbit distance to 0.8 units.
• Scale the plane to 120% of its original size.
• Display the test pattern.
